Inel grad dual 80+100 A1343 Crosby®

De la 60,62 lei

Dimensiune

Anulează

Inel principal de ridicare pentru 1 sau 2 brate de lant – A 1343 – Grade 100 Welded Master Link CROSBY®

Greutate	Nu se aplică
Dimensiune	12x120x60 mm, 13x120x60 mm, 17x160x90 mm, 19x160x90 mm, 22x170x90 mm, 22x275x145 mm, 25x210x115 mm, 28x275x145 mm, 31x275x145 mm, 36x285x155 mm, 38x270x140 mm, 40x270x140 mm, 50x380x200 mm, 51x390x215 mm, 57x406x203 mm

Date tehnice

Size	A-1343	Weight Each	For use as Grade 100 Chain Sling		For use as Grade 80 Chain Sling		WLL	Proof Load	Dimesions (mm)
	Stock No. S.C.	Kg	Single Leg Chain Size mm	Double Leg Chain Size mm	Single Leg Chain Size mm	Double Leg Chain Size mm	t	t	A	B	C
12x1	1247069	0.30	6	-	6-7	6	1.6	4	12	60	120
13x2	1247076	0.36	7-8	6	8	7	2.5	6.3	13	60	120
17x3	1247087	0.86	10	7-8	10	8	4.1	10.3	17	90	160
19x4A	1247096	1.08	13	10	13	10	6.7	16.8	19	90	160
22x4B	1247115	1.59	13	10	16	13	8.5	21.3	22	90	170
25x5	1247124	2.43	16	13	18-19	16	11.5	28.8	25	115	210
28x6	1247133	3.91	16-18	13	18-20	16	13	32.5	28	145	275
31x7	1247142	4.86	19-20	16	22-23	18-20	17	42.5	31	145	275
36x8	1247151	6.87	22-23	18-20	26	22-23	24	60	36	155	285
38x9	1247160	7.63	26	22-23	32	26	31.5	78.8	38	140	270
50x10A	1247165	17.6	32	26	-	32	45	112.5	50	200	380
57x10B	1247172	24.5	-	32	-	-	65.3	163.3	57	203	406
