Carlig S-13326 Grad 100 rotativ sub sarcina cu rulment- S 13326 SHURLOC® Swivel Hooks with Bearing CROSBY®
S-13326 SHUR-LOC® Swivel Hooks with Bearing Crosby® – Suitable for frequent rotation under load.
Forged Alloy Steel – Quenched and Tempered.
Individually Proof Tested at 2-1/2 times the Working Load Limit with certification.
Recessed trigger design is flush with the hook body, protecting the trigger from potential damage.
Easy to operate with enlarged thumb access.
Positive Lock Latch is Self-Locking when hook is loaded.
Rated for both Wire Rope, reference page 117 for Wire Rope, and use with Grade 80/100 Chain.
G-414 Heavy Thimble should be used with wire rope slings.
Trigger repair Kit available (S-4316). Consists of spring, roll pin and trigger.
S-13326 Swivel Hook utilizes anti-friction bearing design which allows hook to rotate freely under load.
The SHUR-LOC® hook, if properly installed and locked, can be used for personnel lifting applications and meets the intent of OSHA Rule 1926.1431(g).
“Look for the Platinum Color – Crosby Grade 100 Alloy Products”. U.S. Patent 5,381,650 and foreign equivalents.
Use in corrosive environment requires shank and nut inspection in accordance with ASME B30.10-1.10.4(b)(5)(c)2009
