Carlig Ochi Gr.8+10 A1329 Crosby®

De la 829,33 lei

Capacitate de ridicare W.L.L.

Anulează

SKU: Nu se aplică Categorie: Carlige turnatorie grad 80+100 Etichete: carlig turnatorie stoc Bucuresti, carlig ochi turnatorie grad dual, carlige turnatorie Crosby, carlig ochi turnatorie grad dual stoc Bucuresti Crosby

Carlig ochi turnatorie Grad dual – A1329 Eye Foundry Hook CROSBY®
Forged Alloy Steel – Quenched and Tempered.
Individually Proof Tested to 2-1/2 times the Working Load Limit with certification.
Each hook has a Product Identification Code (PIC) for material traceability, along with the size and the name Crosby & U.S.A. in raised letters.
Suitable for use with Grade 100 and Grade 80 chain.
Fatigue rated at 1-1/2 times the Working Load Limit at 20,000 cycles.
“Look for the Platinum Color – Crosby Grade 100 Alloy Products.”
Hook can be tip loaded at the reduced Working Load Limit, see below.
Operator must ensure the load is retained properly in the hook

Greutate	Nu se aplică
Capacitate de ridicare W.L.L.	2.6 tone 7/8 mm, 4 tone 10 mm, 6.8 tone 13 mm, 10.3 tone 16 mm, 16 tone 18-20 mm, 21 tone 22-23 mm, 27.1 tone 26 mm, 41 tone 32 mm

Date tehnice

Stock No.	WLL at Saddle of Hook	WLL at Tip of Hook	Chain Size		Weight Each	Dimensions (mm)
	Tone	Tone	in.	mm	Kg	B	D	I	K	L	M	N	O	AA
1026280	2.6	1.3	1/4-5/16	7-8	0.91	39.6	122.4	22.4	39.9	16.0	122.2	63.5	28.7	89
1026289	4.0	2.0	3/8	10	1.72	52.6	147.8	33.0	47.8	20.6	139.7	76.2	35.1	102
1026297	6.8	3.4	1/2	13	3.27	64.3	178.8	38.1	57.2	26.2	180.6	88.9	41.4	114
1026306	10.3	5.1	5/8	16	5.58	76.2	207.5	44.5	64.3	31.8	202.2	101.6	55.6	127
1026315	16.0	8.0	3/4	18-20	10.4	104.9	245.1	55.9	86.1	50.0	273.1	127.0	61.0	165
1026324	21.0	10.0	7/8	22-23	18.4	121.2	280.2	69.1	95.0	57.9	311.2	139.7	78.0	178
1026333	27.1	13.5	1	26	23.5	135.4	302.3	71.9	99.8	65.0	399.6	152.4	84.1	191
1026342	41.0	20.5	1 1/4	32	38.3	167.9	336.6	88.9	110.0	80.0	387.4	165.1	97.5	203
